OPERATING VOLTAGE: 380 V
MAX. POWER: 5 Kw
MOTOR RPM : 1 BASE 750 Rpm, 2 BASE 1500 Rpm
MAX. INPUT CURRENT: 12 A
304 QUALITY STAINLESS STEEL: Stainless steel base variety. C 450 provides high oxidation resistance. Mechanical resistance and friction resistance is very good. Complies with food regulations.
Parts and Accessories are European standards.
|
Delight Boiler (Steam Hot Oil Bottom Dump) |
|
CAPACITY : 100 Kg / BATCH |
|
DEPTH : 55 cm. |
|
DIAMETER : 90 cm. |
|
HEIGHT : 200 cm. |
|
WEIGHT : 620 Kg. |
|
Motor Power : 4 kw + 1kw = 5 Kw |
|
PARTS AND COMPONENTS: |
|
1 |
Motor |
|
2 |
Spiral Bevel |
|
3 |
Motor – Reductor |
|
4 |
Tracked mixer shaft |
|
5 |
Oval win |
|
6 |
Electric hot oil system |
|
7 |
Oil entrance hoose |
|
8 |
Hot Oil Pomp |
|
9 |
Steam way – Sempantin |
|
10 |
Hoods and extractor fan |
|
11 |
Oil entrance and exit |
|
12 |
Engine Chassis |
|
13 |
Boiler Chassis |
|
14 |
Oil Entrance |
|
15 |
Electric panel |
|
16 |
The Throw gear and arms |
|
17 |
Hidrolic throw |
|
18 |
Unloading gate |
|
MACHINE ELEMENTS AND VALUES |
|
1 |
R-S-T-Phase input warning light |
|
2 |
Pako 16 A two-stage switch to M-1 |
|
3 |
M-2 for 1 and 2 start button |
|
4 |
M-2 to 9 A 1 and 2 contactors |
|
5 |
M-2 swich |
|
6 |
M-1, 4 kw – 5,2 Ps - 9 A 3-phase motor |
|
7 |
M-2, 1 kw-1,3 ps – 2,25 A 3-phase motor |
