OPERATING VOLTAGE: 380 V
MAX. POWER: 4,2 Kw
MOTOR RPM : 1 BASE 750 Rpm, 2 BASE 1500 Rpm
MAX. INPUT CURRENT: 8 A
304 QUALITY STAINLESS STEEL: Stainless steel base variety. C 450 provides high oxidation resistance. Mechanical resistance and friction resistance is very good. Complies with food regulations.
Parts and Accessories are European standards.
|
LOKHUM (DELIGHT) BOILER |
|
CAPACITY : 60 Kg / BATCH |
|
DEPTH : 50 cm. |
|
DIAMETER : 90 cm. |
|
HEIGHT : 200 cm. |
|
WEIGHT : 500 Kg. |
|
Motor Power : 2,2 +1,1= 3,3 Kw |
|
PARTS AND COMPONENTS: |
|
1 |
Motor |
|
2 |
Spiral Bevel |
|
3 |
Belt pulley |
|
4 |
Tracked mixer shaft |
|
5 |
Oval win |
|
6 |
Electric hot oil system |
|
7 |
Engine Chassis |
|
8 |
Boiler chassis |
|
9 |
Steam inlet |
|
10 |
Electric panel |
|
11 |
The Throw gear and arms |
|
12 |
Brake-fitting engine |
|
13 |
The unloading gate |
|
MACHINE ELEMENTS AND VALUES |
|
1 |
R-S-T-Phase input warning light |
|
2 |
Pako 16 A two-stage switch to M-1 |
|
3 |
M-2 for 1 and 2 start button |
|
4 |
M-2 to 9 A 1 and 2 contactors |
|
5 |
M-2 swich |
|
6 |
M-1, 2,2 kw - 3 Ps - 5 A 3-phase motor |
|
7 |
M-2 2 kw-2.6 ps - 4.5 A 3-phase motor |
